ELAC Vertex Series 3 IW-VJ63L

ELAC Vertex Series 3 IW-VJ63L

Introduction: The ELAC Vertex Series 3 IW-VJ63L represents the pinnacle of audio technology and is featured throughout ELAC's speaker range. This highly engineered tweeter uses advanced technologies to deliver unmatched sound quality with exceptional clarity and precision. The combination of the Air Motion Transformer (AMT) principle and crystal membrane technology makes it one of the best tweeters on the market.

JET 5 tweeter - Air Motion Transformer (AMT): The ELAC Vertex Series 3 IW-VJ63L uses the Air Motion Transformer principle, which is known for its fast response and great dynamics. With an extended frequency range of over 50 kHz, this tweeter offers unprecedented clarity and detail. Compared to conventional dome tweeters, the Vertex III enables significantly lower distortion and impressive headroom, which ensures authentic sound reproduction. The extremely fast response time ensures that even complex musical passages are reproduced precisely and effortlessly.

AS-XR Crystal Diaphragm Technology: The AS-XR Crystal Diaphragm is made of an aluminum sandwich that is not only known for its impressive rigidity, but also enables an extended frequency range. This special construction contributes to excellent signal accuracy and smooth roll-off. The crystal structure of the aluminum cone ensures excellent large-signal behavior and minimized VAS (volume of the baffle). This allows powerful bass to be output even from small enclosures without losing quality.

Technical details:

• Type: 2½-way, closed housing
• Tweeter: JET Folded Ribbon
• Woofer: 2 x 6” active & 4 x 6” passive Crystal Aluminum Sandwich Cones
• Crossover frequencies: 450 Hz / 2,400 Hz
• Frequency range: 38 to 50,000 Hz
• Sensitivity: 88 dB at 2.83 V/1 m
• Recommended amplifier power: 40 to 200 watts
• Nominal/peak power: 130/170 watts
• Nominal impedance: 4 ohms
• Finish: Black Baffle / White Grille
• Grid: metal, magnetic and paintable
• Accessories: cutting template, manual
• Dimensions: Height: 1184 mm, Width: 248 mm
• Cutout: Height: 1162 mm, Width: 226 mm
• Installation depth: 97 mm

Product highlights:

• Air Motion Transformer technology for lightning-fast response times
• Extended frequency range up to over 50 kHz
• crystal membrane for precise and powerful sound
• Minimized distortion for pure sound reproduction
• Easy installation with included accessories

Experience an incomparable sound experience with the ELAC Vertex Series 3 IW-VJ63L, which is recognized both in the audio industry and by discerning listeners.
