Velodyne DD-12+ Digital Drive Plus Sub

Regular price €4.990,00
Regular price €4.990,00 Sale price €4.990,00
Tax included. Shipping calculated at checkout.
  • Amazon
  • American Express
  • Apple Pay
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • PayPal
  • Union Pay
  • Visa
Velodyne DD-12+ (8527717302620)
Regular price €4.990,00
Regular price €4.990,00 Sale price €4.990,00

New, standard-setting subwoofer series with breathtaking sound, elegant styling and the most advanced technologies: The new Digital DrivePLUS series subwoofers from Velodyne Acoustics, the world's leading manufacturer of active subwoofers, set new standards thanks to fully automatic setup, gigantic output power, real-time bass correction and elegant housing design Standards in deep bass reproduction.

Velodyne DD-12+ Digital Drive Plus Sub

New, standard-setting subwoofer series with breathtaking sound, elegant styling and the most advanced technologies: The new Digital DrivePLUS series subwoofers from Velodyne Acoustics, the world's leading manufacturer of active subwoofers, set new standards thanks to fully automatic setup, gigantic output power, real-time bass correction and elegant housing design Standards in deep bass reproduction.

The Velodyne DD-12+ offers a variety of options for optimizing bass performance thanks to real-time bass correction using Velodyne's specially developed room correction software. DD+ also offers Auto EQPLUS. Thanks to the included software and measuring microphone, the entire calibration and adjustment procedure of the subwoofer to the room conditions and the satellite speakers is carried out fully automatically with just the push of a button within a few minutes. For manual calibration or fine adjustments, simply connect DD+ to your notebook via USB, which will show you the frequency response, phase, transition frequencies and slope. Eight fully parametric equalizers are available to achieve clean and seamless bass reproduction. Crossover frequencies, slope, subsonic filter and phase can be set for the primary setting, but also configured for five different user settings, called presets - all with real-time feedback. A third option for calibration and fine-tuning is to connect DD+ to a TV screen. The subwoofers also have controls on the front for adjusting the volume, crossover and Auto-EQPLUS with immediate feedback on the front LED display. Digital DrivePLUS combines Velodyne's accumulated know-how and many years of experience in building subwoofers. The DD+ series features completely newly developed drivers with twice as much travel as their predecessors. Thanks to Velodyne's specially developed Digital High-Gain Servo technology and patented Class D "Energy Recovery System" (ERS) amplifier with over 3000 watts of impulse power, DD+ is the lowest distortion bass system in the world at less than 0.5% and offers 4% more distortion than previous models .5 to 6 dB increased output power.

All four models of the Digital DrivePLUS series (DD-10+, DD-12+, DD-15+ and DD-18+) have drivers with ultra-strong drive magnets weighing at least 15 kg, fiberglass and Rohacell sandwich membranes and six-layer, hand-wound Voice coils for more output power and better heat dissipation. The entire DD+ technology is packed into an amazingly compact and subtly curved housing, which is available in either black, satin cherry wood or walnut veneer.

“In 2003, we introduced our original Digital Drive series, which quickly became the recognized standard for undistorted bass reproduction,” says Bruce Hall, general manager of Velodyne. “We are pleased to have once again raised the bar with even lower low-frequency distortion, simplified automatic setup, exciting design and other new features. The new DD+ series is indeed the culmination of all our experience from 27 years of subwoofer manufacturing.”

Downloads

Technical specification

DD-10+ Velodyne DD-12+ DD-15+ DD-18+
Driver 10" forward firing 12" forward firing 15" forward firing 18" forward firing
Amplifier Class D 3000 watts dynamic
1250 watts RMS power
Frequency Response: Overall
Frequency Response: (±3dB)
10.5 - 300Hz
18.7 - 120Hz
10.2 - 300Hz
17.0 - 120Hz
9.0 - 300Hz
14.6 - 120Hz
8.8 - 300Hz
14.4 - 120Hz
THD < 0.5% (typical)
High pass crossover 80 or 100 Hz at 6 dB/octave
Low pass crossover 40 Hz to 199 Hz (variable in 1 Hz increments) selectable slope
Default: 80 Hz @ 24 dB/Octave
phase 0 to 180 degrees (variable in 15 degree increments)
Polarity Adjustable (+/-)
Magnet structure 35 lbs. 39.7 lbs.
Voice Coil Six-layer, 65mm Six layer, 75mm
Cone Fiberglass Rohacell laminates
Input LFE (Mono) Line level (RCA), Nominal Impedance 47K, Balanced (XLR), Nominal Impedance 10K
Input L&R Line level (RCA & XLR)
Input microphones Balanced (Mini-XLR, cable included)
Input Speaker Level (L&R) Bare wire, banana plugs, or spade lugs
Output Thru (L&R) Line level (RCA & XLR)
Output (L&R), High Pass (L&R) Line level (RCA & XLR)
Accessories included Full feature remote control, DD+ accessory kit and video cable
Finishes Black gloss ebony, satin cherry or walnut
Dimensions (H/W/D) (includes feet and connectors) 14.2” x 13” x 16.6” (36 x 33 x 42 cm) 15.8” x 14.4” x 18” (40 x 37 x 46 cm) 20” x 18.1” x 22.5” (51 x 46 x 57cm) 22.7” x 20.7” x 25.6” (58 x 53 x 65cm)
Shipping Weight (approx) 75 lbs. 85 lbs. 120 lbs. 142 lbs.
